Extensibility: Authorization

Meshery features an extensible authorization system that offers the ability to deliver fine-grained access control across its web-based user interface, Meshery UI.

Authorization Keys

The extensible authorization system consists of a large set of keys. Each key uniquely represents a specific capability, for example, the ability to view, edit, or delete a Connection. With the help of these keys, the system evaluates permissions at runtime to render the UI, offering both a secure management system and a customizable user experience.

Key Naming and Scoping Conventions

Permission keys in @meshery/schemas are generated dynamically using the following formula: PascalCase(Theme) + PascalCase(Function)

• Theme (Domain Capability): Represents the high-level business domain/capability that governs the action (e.g. Catalog Management, Lifecycle Management).
• Function (Operation): Represents the specific operation being performed (e.g. Unpublish Design, Evaluate Relationships).

Domain Scoping vs. UI Layout

Keys are categorized by their domain of authority rather than the UI component or file path where they are used.

For example, the component MesheryPatternCard (which resides in the designs/patterns directory) uses the key CatalogManagementUnpublishDesign because publishing/unpublishing a design is a Catalog Management action (making it public or private in the catalog), even though the card itself represents a pattern/design UI element.

Adding a New Permission Key

Permission keys are defined and managed centrally via an automated Google Spreadsheet workflow. The spreadsheet serves as the authoritative source of truth, while @meshery/schemas compiles and publishes the generated Go and TypeScript artifacts consumed by downstream projects:

1. Spreadsheet Registration: Keys are registered in the central permissions spreadsheet.
2. Meshery Schemas Automation: A GitHub Actions workflow automatically imports the spreadsheet, updates build/permissions.csv, and compiles the definitions into Go and TypeScript libraries.
3. Dynamic Consumption: Downstream projects (meshery/meshery backend and React UI) consume the generated models and constants dynamically, removing the need for duplicate, hardcoded constants.

Step-by-Step Guide

Follow these steps to generate, register, sync, and wire up a new permission key.

Phase 1: Define Key in Spreadsheet

Step 1: Generate a UUID v4

Generate a unique, lowercase UUID v4 for the new permission key:



		uuidgen | tr '[:upper:]' '[:lower:]'


Step 2: Add to the Permissions Spreadsheet

Add a new row to the authoritative Permissions Spreadsheet. Ensure the following columns are set:

• Theme: The high-level category (e.g. Catalog Management).
• Category: Specific feature area (e.g. Designs).
• Function: Human-readable operation name (e.g. Evaluate Relationships). This value becomes key.function in the Provider API.
• Feature: Feature description (e.g. Evaluate relationships inside a design).
• Key ID: The generated UUID from Step 1.
• Local Provider: Set to TRUE if this key should be seeded for the Local Provider database.

Step 3: Run the Schema Sync & Generation Workflow

Once added to the spreadsheet, the GitHub Actions workflow generate-artifacts-from-schemas.yml in meshery/schemas runs automatically on a daily schedule (and can also be triggered manually) to sync the spreadsheet keys to the local build/permissions.csv.

This workflow automatically executes the generators to produce:

• Go constants: models/permissions/permissions.go
• TypeScript definitions: typescript/permissions.ts

These generated files are committed to the master branch and published as part of the @meshery/schemas package.

Phase 2: Backend Sync

Step 4: Wait for keys.csv Sync in Meshery

The local database seeds are populated via server/permissions/keys.csv in the meshery/meshery repository. This file is automatically kept in sync with the spreadsheet by the Import Keys workflow, which runs daily.

On startup, Meshery Server’s SeedKeys seeds these keys into the database.

Phase 3: Wire Key in the UI

Step 5: Direct Import from Schemas

Because Meshery UI depends on @meshery/schemas, you can gate new UI behavior by importing Keys directly from @meshery/schemas/permissions. There is no hand-maintained constant map to update: ui/utils/permission_constants.ts was removed once every call site had been migrated to the generated keys.

Simply import the Keys object directly from @meshery/schemas/permissions in your component:



		import { Keys } from '@meshery/schemas/permissions';


Step 6: Gate the Component

Prefer the useHasPermission hook from Sistent, which takes the whole key object:



		import { useHasPermission } from '@sistent/sistent';
import { Keys } from '@meshery/schemas/permissions';

const canEvaluate = useHasPermission(Keys.CatalogManagementEvaluateRelationships);

return (
  <Button disabled={!canEvaluate} onClick={handleEvaluate}>
    Evaluate Relationships
  </Button>
);


Sistent controls also accept the key directly as a permissionKey prop, which is the shortest form when the only effect is to disable the control:



		<Button permissionKey={Keys.CatalogManagementEvaluateRelationships} onClick={handleEvaluate}>
  Evaluate Relationships
</Button>


See Gating spellings for when to reach for the older CAN(...) utility instead.

Step 7: Verify End-to-End

1. Run make ui-lint to verify that there are no formatting or typescript errors.
2. Restart Meshery Server (or reset database settings) to seed the local provider with the new key.
3. Login and verify that your UI component gates correctly.

Reference: End-to-End Key Mapping

This example shows how the Evaluate Relationships key is wired across each layer of the application:

1. Provider API key object (excerpt from API output):



   		{
     "id": "c7752be7-5c0f-465d-a8ba-5594acd08b93",
     "function": "Evaluate Relationships",
     "category": "Catalog Management",
     "subcategory": "Designs"
   }



2. TypeScript constant from @meshery/schemas:



   		export const Keys = {
     CatalogManagementEvaluateRelationships: {
       id: "c7752be7-5c0f-465d-a8ba-5594acd08b93",
       category: "Catalog Management",
       subcategory: "Designs",
       function: "Evaluate Relationships",
       description: "Evaluate relationships inside a design"
     }
   }



3. CASL rule built on login - id becomes the rule’s action, function its subject:



   		{ action: "c7752be7-5c0f-465d-a8ba-5594acd08b93", subject: "evaluate relationships" }



4. React Component Gating (see Gating spellings for the other two forms):



   		import { useHasPermission } from '@sistent/sistent';
   import { Keys } from '@meshery/schemas/permissions';

   const canEvaluate = useHasPermission(Keys.CatalogManagementEvaluateRelationships);
   return canEvaluate ? <EvaluateRelationshipsButton /> : null;



Where Permission Keys Are Stored in the Browser

When testing permission keys locally, the main client-side caches are stored under sessionStorage and Cookies (not localStorage):

On login, Meshery either reuses sessionStorage.keys or refetches from the provider, then updates CASL. The Keys object is generated source code—not browser storage—but every gating spelling compares those constants against the CASL rules built from the stored provider keys.

Inspect keys in DevTools (Application → Session Storage):



		JSON.parse(sessionStorage.getItem('keys'))
JSON.parse(sessionStorage.getItem('currentOrg'))


You can also check cookies under DevTools (Application → Storage → Cookies).

Troubleshooting Permissions

Use this checklist when a gated button does not appear, permissions look stale after a role change, or a newly added key does not work end-to-end.

1. Confirm the provider returned the key

In DevTools Network, check the response for: GET /api/identity/orgs/{orgId}/users/keys Verify your UUID is in the keys array. The API’s function is what CASL stores as the rule subject (lower-cased), so it must match the function on the Keys entry you are gating with.

2. Clear stale browser cache

Meshery reuses sessionStorage.keys until the org changes or keys are refetched:



		sessionStorage.removeItem('keys');
location.reload();


3. Verify the generated key

In Keys, published by @meshery/schemas:

• id = the key UUID, matched against the CASL rule’s action
• function = the human-readable operation name, matched against the CASL rule’s subject (capitalization differences are normalized by _.lowerCase)

If the key is missing from Keys altogether, it has not made it through the spreadsheet → schemas generation described above; re-run Phase 1 rather than declaring it locally.

4. Confirm CASL loaded the rules

• Redux DevTools: check state.ui.keys for the expected UUID.
• Session Storage: confirm sessionStorage.keys is populated.
• Loader: LoadSessionGuard must finish loading before CAN(...) returns meaningful results.

5. Local Provider: confirm database seeding

The key must be in server/permissions/keys.csv with Local Provider = TRUE. Restart Meshery Server (or reset the local DB) after the CSV updates.

6. Remote Provider: confirm role assignment

Keys come from roles assigned in the Remote Provider admin UI. An empty API response usually means a role/keychain issue—not a missing entry in the generated Keys alone.

7. Verify browser cookies and session validity

Verify that the token cookie is set and not expired:

• Open DevTools Application -> Storage -> Cookies and select the Meshery site URL.
• Confirm that the token cookie is present. If it is missing or has expired, you will be redirected to the login page or receive a 401 Unauthorized response when fetching keys.
• Check that the meshery-provider cookie matches the intended provider (e.g., Local or Meshery).

Common symptoms

Authorization Framework

Meshery utilizes CASL (JS-based permission framework) to evaluate any given user’s set of session keys against the built-in keyhooks populated through each individual Meshery UI page. This allows for granular control over the UI, empowering you to tailor your Meshery experience to your organization’s needs by limiting access to specific features and functionalities based on the user’s assigned keys.

Introduction to CASL.js

CASL.js is an isomorphic authorization JavaScript library which restricts what resources a given client is allowed to access. It’s designed to be incrementally adoptable and can easily scale between a simple claim based and fully featured subject and attribute based authorization. It makes it easy to manage and share permissions/keys across UI components, API services, and database queries.

Upon user login, the provider returns the list of authorized permission keys. Those keys are used to build and update the CASL ability rules on the frontend, and each key is registered as a rule of { action: key.id, subject: lowerCase(key.function) }. Every gate in Meshery UI is a query against that one ability instance.

Gating spellings

Three spellings exist, and they are equivalent - all three end up calling the same CASL ability. Each takes a key from @meshery/schemas/permissions, whose entries carry id, function, category, subcategory and description.

1. useHasPermission hook - the usual spelling, and the one to reach for in new code. Pass the whole key object; the hook resolves id and function for you.



   		import { useHasPermission } from '@sistent/sistent';
   import { Keys } from '@meshery/schemas/permissions';

   const canDelete = useHasPermission(Keys.LifecycleManagementDeleteAConnection);

   return canDelete ? <Button id="delete-connection">Delete</Button> : null;



2. permissionKey prop - Sistent controls gate themselves. By default the control renders disabled behind a shield icon whose tooltip names the missing key; pass permissionAction="hide" to render nothing instead.



   		import { Keys } from '@meshery/schemas/permissions';

   <Button id="delete-connection" permissionKey={Keys.LifecycleManagementDeleteAConnection}>
     Delete
   </Button>



3. CAN(...) utility - the original spelling, still used where a hook cannot be called (outside a component, or inside a callback). It takes the two fields separately rather than the key object.



   		import CAN from '@/utils/can';
   import { Keys } from '@meshery/schemas/permissions';

   const key = Keys.LifecycleManagementDeleteAConnection;
   const canDelete = CAN(key.id, key.function);



Access gating and control gating

CASL gates Meshery UI at two levels, and they are not the same thing:

• Access gating replaces a page’s whole content with the permission-denied page when your session lacks the key that page requires.
• Control gating renders the page, and hides or disables only the individual affordances within it - a button, a link, a menu item - that you lack the key for.

Every content-bearing page in Meshery UI except the landing page (/) is access-gated; that one exception is described below. Where the page owns RTK Query hooks, pass skip on the same flag so a denied session issues no request at all.

Access gating is a presentation control, not an enforcement boundary. Meshery Server authenticates every request, and authorization is decided by the configured Remote Provider and enforced per handler on the server. An ungated page therefore never implies an ungated API.

Authorization using Local Provider

Meshery’s built-in identity provider, “Local” Provider, operates with a large set of predefined keys interspersed throughout Meshery UI and persisted in Meshery Database. These keys are used to evaluate the permissions of a given user and render the UI accordingly. Each persisted key carries an id, a function (the operation it permits), and a category/subcategory pair that places it in a domain - the same shape the Remote Provider returns, so the UI gates identically under either provider.
